Setting up Samba as an Active Directory Domain Controller on Debian 9 Stretch

Introduction

Samba is great project and if wont make Samba AD DC today is very simple. More about Samba look at https://www.samba.org/.

Preparing the Installation

  • select hostname(dc1.mydomain.local),domain name(mydomain.local)
  • installation and configure of time server (ntp)
  • installation and configure of domain name system (bind9)



Set hostname of my Samba ad dc server:

hostnamectl set-hostname dc1.mydomain.local

Edit hosts:

nano /etc/hosts

127.0.0.1      localhost localhost.localdomain
127.0.1.1      localhost localhost.localdomain

192.168.0.100  dc1.mydomain.local dc1


Installation and configure of time server (ntp):

apt-get install ntp

Change settings in ntp.conf

nano /etc/ntp.conf

logfile   /var/log/ntp.log
driftfile /var/lib/ntp/ntp.drift
ntpsigndsocket /var/lib/samba/ntp_signd/

pool 0.debian.pool.ntp.org iburst
pool 1.debian.pool.ntp.org iburst
pool 2.debian.pool.ntp.org iburst
pool 3.debian.pool.ntp.org iburst

restrict -4 default kod notrap nomodify nopeer noquery limited
restrict 127.0.0.1
restrict source notrap nomodify noquery
restrict default kod nomodify notrap nopeer mssntp

Installation and configure of domain name system (bind9):

Instalirati bind9 paket:

apt-get install bind9

Configure neamed.conf.options

nano /etc/bind/named.conf.options

acl internal {
   127.0.0.0/16;
   192.168.0.0/16;
};

options {

        auth-nxdomain yes;
        directory "/var/cache/bind";
        notify no;
        empty-zones-enable no;
        listen-on-v6 { none; };

        forwarders {
                8.8.8.8;
                8.8.4.4;
        };

        allow-query { internal; };
        allow-recursion { internal; };
        allow-transfer { none; };
};

Finale step start service and test ntp and bind9:

systemctl restart ntp.service bind9.service

Set in resolv.conf our bind9:

nano /etc/resolv.conf

search mydomain.local
nameserver 192.168.0.100

Now test bind9:

Test the localhost forward zone):

host -t A localhost 127.0.0.1

Default respond is:

Using domain server:
Name: 127.0.0.1
Address: 127.0.0.1#53
Aliases:

localhost has address 127.0.0.1

To test the 0.0.127.in-addr.arpa reverse zone:

host -t PTR 127.0.0.1 127.0.0.1

Default respond is:

Using domain server:
Name: 127.0.0.1
Address: 127.0.0.1#53
Aliases:

1.0.0.127.in-addr.arpa domain name pointer localhost.

Test NTP server:

ntpdate -q 192.168.100.31

Default respond is:

server 192.168.0.100, stratum 2, offset -0.000073, delay 0.02602
24 Apr 12:10:30 ntpdate[10143]: adjust time server 192.168.0.100 offset -0.000073 sec



Installing Kerberos & Samba and configure Bind9 with Samba:

  • Installing Kerberos and configure
  • Installing Samba and configure
  • Configure Bind9 to work with Samba

Installing Kerberos and configure:

apt-get install krb5-config krb5-user

Configure krb5.conf

nano /etc/krb5.conf

[libdefaults]
        default_realm = MYDOMAIN.LOCAL
        dns_lookup_realm = false
        dns_lookup_kdc = true

[realms]
        MYDOMAIN.LOCAL = {
                kdc = dc1.mydomain.local
                admin_server = dc1.mydomain.local
                default_domain = mydomain.local
        }

[domain_realm]

        .mydomain.local = MYDOMAIN.LOCAL
        mydomain.local = MYDOMAIN.LOCAL

Installing Samba and configure:

Debian bring Samba 4.5.16 but that version don't have JSON module (Need 4.7+ for JSON), and I find great repository apt.van-belle.nl by Louis van Belle (Please feel to free Donate to Louis).

Add van-belle.nl repos:

wget -O - http://apt.van-belle.nl/louis-van-belle.gpg-key.asc | apt-key add -

echo "# AptVanBelle repo for samba." | sudo tee /etc/apt/sources.list.d/van-belle.list

echo "deb http://apt.van-belle.nl/debian stretch-samba410 main contrib non-free" | sudo tee -a /etc/apt/sources.list.d/van-belle.list

apt-get update

Install samba:

apt-get install samba winbind attr

Configure service samba for AD DC:

systemctl stop smbd nmbd winbind
systemctl mask smbd nmbd winbind
systemctl disable smbd nmbd winbind
systemctl unmask samba-ad-dc
systemctl enable samba-ad-dc
systemctl daemon-reload

Configure Samba as AD DC:

If exist old configuration of samba /etc/samba/smb.conf then make backup of config and delete.

cp /etc/samba/smb.conf /etc/samba/smb.conf.bck
rm /etc/samba/smb.conf

samba-tool domain provision --use-rfc2307 --realm MYDOMAIN.LOCAL --domain MYDOMAIN --server-role dc --dns-backend=BIND9_DLZ  --adminpass StrongPassword

Configure Bind9 to work with Samba:

Add under section options { }

nano /etc/bind/named.conf.options

allow-update { 192.168.0.100; };
tkey-gssapi-keytab "/var/lib/samba/bind-dns/dns.keytab";

Add bind-dns include in named.conf

nano /etc/bind/named.conf

include "/var/lib/samba/bind-dns/named.conf";

Set pemission for Bind9:

chown root:bind /etc/krb5.conf

Set permission for NTP:

chown root:ntp /var/lib/samba/ntp_signd/
chmod 750 /var/lib/samba/ntp_signd/

Restartati all services:

systemctl restart bind9.service ntp.service samba-ad-dc.service

Test Kerberos:

kinit administrator
klist

Test DNS over Samba:

samba_upgradedns --dns-backend=BIND9_DLZ
samba_dnsupdate --verbose

Test Samba:

samba-tool domain info 192.168.0.100
net ads info
net rpc info -U administrator
wbinfo -P

Congratulations enjoy in Samba World.
